High-efficiency, ultra-lightweight progress-capture pulley
NANO TRAXION is an ultra-lightweight (53 g) and compact progress-capture pulley designed for rescue. Sealed ball bearings provide excellent efficiency (91%).
-
Ultra-lightweight and compact: Only 53 g
Very compact
Hole allows an Sm’D carabiner to be connected to the pulley with a cord, making the device loss-proof
Designed for rescue
High efficiency: Sealed ball bearings provide excellent efficiency (91%)
Works even on frozen or muddy ropes
For use on 7 to 11 mm diameter ropes
Rope installation diagrams are engraved inside the pulley
Certification(s): CE EN 567, UKCA, UIAA
Compatible with the RAD LINE 6 mm cord
Compatible with the PUR’LINE 6 mm cord only for hauling a pack
-
Weight: 85 g
Min. rope diameter: 8 mm
Max. rope diameter: 11 mm
Sheave type: Sealed ball bearings
Sheave diameter: 27 mm
Working load: 2 x 2.5 = 5 kN
Breaking strength: 2 x 7,5 = 15 kN
Working load as progress capture pulley: 2,5 kN
Breaking strength as progress capture pulley: 4 kN
